model YW-918
Detection channel height(фmm) 4010 4012 4015 4020 4025 4030 4035
Sensitivity Fe (фmm) 0.8 1.0 1.2 1.5 2.0 2.5 3.0
Non-Fe (фmm) 1.2 1.5 2.0 2.5 3.0 3.5 4.0
SUS (фmm) 1.5 2.0 2.5 3.0 3.5 4.0 4.5
Body material The whole machine is made of 304 stainless steel
Alarm method Automatically shut down when foreiqn matter is detected, and output a 12V buzzer alarm sound (customized: Flap,Air blow,Pusher,Swing arm,Sink.)
Machine size (L:1500 *W:920*H:1010) please refer to the actual product for
customized product size
Machine weight ≈200kg
Power Power:220V 50Hz Power:120W
Weighing capacity <20 kg speed:25~30m/min (not adjustable)
Working desk Height:700mm(customizable height)

Product Size/Parameter918_02.jpg918_04.jpg

Product Feature Display806_10.jpg806_09.jpg806_08.jpgimagetools5.jpg

Customizable Rejection System


Packaging & Shipping


Product Moder



Industry Use Scope

suitable for detecting metal foreian obiects mixed in the oroduction of products or raw materials in

industries such as food, seafood processing, toys, clothing, footwear, chemicals, leather, knitted

fabrics, wood, etc


FAQ

Q1: What is the detection accuracy of the equipment?How small metal impurities can it detect?

A1: The detection accuracy (sensitivity) of the equipment depends on the product aperture, material characteristics, and metal type. For example,
for general food or plastic pellets, our high-sensitivity models can stably detect metal balls with a diameter of 0.3mm to 0.8mm.
We recommend that you provide a small number of samples, and we will determine the exact detection accuracy for you through free sample testing and issue a test report.

Q2: Can the equipment operate stably if our production environment(e.g., humidity, temperature, vibration) is harsh?

A2: Absolutely. Our metal detectors are designed with an IP54 or higher protection rating, providing excellent dust and water resistance.
Meanwhile, the core of the equipment adopts advanced digital signal processing technology and automatic phase tracking functions,
which can effectively suppress environmental interference and product effects (such as humid and salty foods), ensuring high stability and reliability even in harsh industrial environments.

Q3: Can customization be done according to our specific production line requirements?

A3: Yes. We have a professional design team and can provide customization services, including non-standard apertures, special conveyor belts (e.g., PU, Teflon),
different materials (e.g., 304 stainless steel), and integrated rejection devices (e.g., flap, pusher, air jet).
Please provide your specific production line layout and requirements, and we will customize a solution tailored to your needs.

Q4: What is the response speed of after-sales technical support?

A4: We promise to provide 24/7 online technical consultation. For general issues, we guarantee a response within 2 hours
for emergency failures, we offer remote diagnosis. If the problem cannot be solved remotely,
we will arrange for engineers to provide on-site services based on the situation, ensuring that your downtime is minimized.
